Replace the oil after the first 30 working hours and every 250 working hours with GX85-W140
transmission oil or equivalent.
1. Drain plug - 2. Fill plug - 3. Funnel
A. Central Gearbox
Figure 26. Replace the Central Gearbox Oil
