Point
Guide plate
Stalk
Linch pin with safety bar
Share base with quick-change system
Wing share
The machine can be used with various share systems that enable both
deep soil cultivation and shallow full-surface soil cultivation.
The points and the wing shares can be mounted as hard-faced equip‐
ment.
Hard-faced points or wing shares have a signicantly longer service life
than points or wing shares that are not hard-faced.
When converting to another share system or when replacing worn
parts, the share bases with a quick-change system are removed from
the stalk.
The user can then replace the corresponding components separately
on the share base.
INFORMATION
Adherence to the 3 m transport width:
For machines with a working width of 300 cm or 400 cm
and equipped with the duckfoot-shares KG37 or KG37H:
– To ensure adherence to the 3 m transport width, the
duckfoot-shares KG35 or KG35H must be mounted on
the two outer tines.
Operation
