Lennox iComfort E30

17
E30 Smart Hub
Remove jumper between R and W2 if present.
Not removing may cause erroneous alert code 125
to appear.
Aquastat provided by installer. Set air handler
continuous fan speed to desired heating CFM
Figure 11. Hot Water Coil Heat with Aquastat Blower Control - Conventional Air Handler (CBX32MV(-6) or CBX40UHV)
