3
Shipping and Packing List
Quantity Description
1 iComfort
®
E30 smart thermostat includes a Smart Hub, HD Display, Mag-Mount and
optional use wall plate.
6 Mounting screws (#6 X 1.25” pan head) - Mag-Mount requires 4 and Smart Hub 2.
6 Wall anchors (alligator anged solid wall anchors)
1 Installation and setup guide
1 User guide
1 Checklist
1 Warranty certicate
IMPORTANT
The iComfort E30 smart thermostat CAN NOT be connected as a communicating
device to indoor or outdoor units. Only conventional 24VAC wiring to indoor and
outdoor units is supported.
WARNING
This product contains a chemical known to the State of California to cause cancer,
birth defects, or other reproductive harm.
NOTE: Due to Lennox’ ongoing commitment to quality, features and options are
subject to change without notice and without incurring liability.
Operating and Storage Environment, Electrical and Dimensions
• Operating Temperature is -40°F to 175°F (-40°C to 79°C)
• Shipping and storage temperature range is -40°F to 185°F (-40°C to 85°C)
• Operating humidity range is 10% to 90% non-condensing at 104°F (40°C)
• Storage humidity range is 5% to 95% non-condensing at 104°F (40°C)
• E30 Smart Hub Power Input: 24VAC, 1AMP at 60Hz.
• E30 Smart Hub DC Power Output: 12VDC (to Mag-Mount/HD Display)
• Dimensions (H x W x D):
» Mag-Mount: 3-1/4” x 3-1/4” x 1/2” (83 x 83 x 13 mm)
» HD Display: 5” x 7-1/2” x 1” (127 x 19 x 25 mm)
» E30 Smart Hub: 11-1/2” x 7-1/8” x 1-7/8” (292 mm x 181 mm x 48 mm) -
antenna length is 7-1/4” (184 mm)
Installation Recommendations
WARNING
Improper installation, adjustment, alteration, ser vice or maintenance can cause
property damage, personal injury or loss of life.
Installation and service must be performed by a li censed professional HVAC
installer (or equivalent) or a service agency.
Before beginning installation, note the type of equipment, number of stages, and
any accessories being installed.
Do
• Read this entire document, noting which procedures pertain to your specic
equipment and system requirements.
• Make sure that all wiring conforms to local and national building and electrical
codes and ordinances.
Do Not
• Install on voltages higher than 30VAC.
• Exceed 300 feet (91 meters) run when using 18 #AWG thermostat wire or larger.
• Allow power load from any thermostat connection to be more than 1 AMP.
Smart Hub Installation, External Components, LEDs, Terminals & Jumpers
1. Things to consider when installing the Smart Hub:
• Install near the indoor unit such that there is a direct path to the approximate
location of the home Wi-Fi access point (the signal is not blocked by the
indoor unit or duct work, for example).
• Can be attached to a vertical surface such as a wall stud or roof truss web,
or to a horizontal surface such as a oor or ceiling joist, or a roof rafter.
• Smart Hub antenna should be positioned such that it is roughly vertical, no
matter the orientation of the Smart Hub, itself.
• Do not install the Smart Hub on the indoor unit, duct work, or other
equipment that could induce vibration in the Smart Hub.
• Do not install the Smart Hub on or near large metal objects. This could
adversely affect the range and directional coverage of the Smart Hub Wi-Fi
signal.
• If the Smart Hub MUST be installed on a metal object, orientate the antenna
perpendicular to the metal surface.
• In all cases, the Smart Hub antenna orientation may need to be adjusted to
obtain best Wi-Fi results.
