Lennox iComfort E30

33
Reset
Table 12. Utilities
Parameter Description
Restart Smart
Hub
Restarts the Smart Hub.
Re-congure
System
Re-congure HVAC system.
Reset HVAC
Equipment
Resets all HVAC equipment.
Factory Reset
Thermostat
Resets thermostat to factory default settings.
Factory Reset
Smart Hub
Resets Smart Hub parameters back to factory default.
notiFiCations
This section will list active notications and service alerts. Service alerts codes are
as follows:
Table 13. Service Alert Codes
Alert Code Description
3000 Filter 1
3001 Filter 2
3002 Humidier pad
3003 UV light
3004 Maintenance
3005 PureAir maintenance
4000 User Wi-Fi state change, disabled.
4001 Firmware download failed
4002 Image le download failed
tEsts
Select Test to check for any of the applicable relays, inputs and 24VAC voltage:
Available function tests are (based on system conguration) - Blower, HP Heat -
1st Stage, HP Heat - 2nd Stage, Cooling - 1st Stage, Cooling - 2nd Stage, Electric
Heat - 1st Stage, Humidication.
• Specic relays tested if applicable are W1, W2, W3, Y1, Y2, O, G, Humidication,
and Dehumidication (open or closed)
• Interlock relay (open or closed)
• Auto-start delay (on or off)
• Outdoor temperature
• Discharge air temperature
• Various inputs are on or off (i.e., Y1, Y2, O, W1, G).
• 24VAC voltage (range between 18 and 30VAC is acceptable)
By default all tests are selected, you may de-select or select all or individually
enabling or disabling each test by touching the individual test option on the screen.
Once your selections have been made, proceed by touching the start test button
along the bottom of the screen.
When a specic set of tests are completed the results will be displayed on the
screen next to the tested item. Touch continue to proceed to the next set of test
items. Once all tests are completed press done to return to the touch tests to run
screen. Touch the left arrow at the top left side of screen to return to the Dealer
Control Center. Maximum time in test mode is 30 minutes. Also defrost testing will
only be energized for 30 seconds.
DiagnostiCs
This screen allows the installer to verify the current operational state of the air
handler or furnace. Diagnostics results are for active various inputs, voltage, delays
and relays.
Touch the left arrow at the top left side of screen to return to the Dealer Control
Center.
installation rEport
• Overview: The overview screen provides information on dealer and customer
information. Also included under day of install section is information on conditions
at the time of installation. Information includes date, time indoor and outdoor
temperatures and indoor humidity.
• System: Information to complete is System name, model number and other
system information.
• Indoor Unit (air handler / furnace): name, model number, serial and other
information.
NOTE: Installation Report is not available until after exiting the dealer control
center following commissioning. Return to the Dealer Control Center from
the home screen to view the installation report.
