icomfort Touch 7−Day Programmable Communicating Thermostat
Page 5
Setting time and date
Use the arrows to select Time and Date; press edit (see fig-
ure 7). Press next step to proceed to the Set current time
and date" screen (figure 8).
tests
setup HELP
system settings
to adjust a setting, high-
light it, then press edit.
Current Value:
(April 10, 2010, 09:23 AM)
Time and Date
Daylight Saving
Time
Circulate Fan ON
Time
Dealer Name
Dealer Address
next step
edit
back
Figure 7. View/edit time and date
WhenTime and Date" screen appears, enter the correct date
as follows:
Press one of the time and date boxes − the text will
change to white type in a dark box (for example, press the
10" box in figure 8).
Press the up/down arrows to change the data.
Press other boxes and adjust with the arrows for all time
and date information. When the date and time is correct,
press save to save settings and return to previous set-
tings screen.
adjust
Time and Date
10 :19 AM
Apr 10 2010
setup HELP
save
cancel
Figure 8. Set current time and date
NOTE − After setting the time and date, if you don’t need to
add any non−communicating devices, you may wish to accept
the default system parameters and skip forward to tests". To
do so, repeatedly press next step on each screen until you
get to the tests screen. From there, you can check the sys-
tems operation. Thereafter, should you need to change a
communicating device parameter, access those settings by
pressing the equipment tab in the installer section.
About screen
The about" screen provides information about the installed
equipment that has been discovered. Use the arrow buttons
to scroll to a device; then press the about button. Again, use
the arrow buttons to view additional information about the se-
lected device. When finished viewing, press the back button.
press about for more
information on a high-
lighted device
HP
XP17−036−230−01
5910M12345
Furnace
SLP98UH−
090V36C−01
5910G17546
Thermostat
49W95
A110A00070
system devices
next step
about
back
setup HELP
device description
HP
Unit Nominal
Capacity
36.0000kBTUs
Number of
Heating Stages
2
Number of
Cooling Stages
back
device feature list
setup HELP
Figure 9. Using the about" screen
