8.Toinstallanewharddiskdriveintothebluebracket,exthebracketandalignpin1,pin2,pin3,
andpin4onthebracketwiththecorrespondingholesintheharddiskdrive.Donottouchthecircuit
board5onthebottomoftheharddiskdrive.
Figure54.Installingtheharddiskdriveintothebracket
9.Slidethenewsecondaryharddiskdriveintothebracketuntilitsnapsintoposition.
3
4
5
6 7
8
Figure55.Installingthesecondaryharddiskdrive
10.Connectthesignalcableandthepowercabletotheprimaryharddiskdriveandsecondaryhard
diskdrive.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage93.
