7.Alignthenewinternalspeakerwiththefourmetalclips1ontheinnersideofchassis,andthenslidethe
speakertotherightuntilitsnapsintoposition.
Figure78.Installingtheinternalspeaker
8.Connecttheinternalspeakercabletotheinternalspeakerconnectoronthesystemboard.See
“Locatingpartsonthesystemboard”onpage12.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage93.
ReplacingthefrontaudioandUSBassembly
Attention:
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.
ThissectionprovidesinstructionsonhowtoreplacethefrontaudioandUSBassembly.
ToreplacethefrontaudioandUSBassembly,dothefollowing:
1.Turnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.
2.Removethecomputercover.See“Removingthecomputercover”onpage32.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage32.
Chapter5.Installingorreplacinghardware75
