3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage32.
4.Locatethepowerswitch.See“Locatingcomponents”onpage11.
5.Pressthereleasetab1asshownandpivotthedrivebayassemblyupward.
Figure86.Pivotingthedrivebayassemblyupward
6.Disconnectthepowerswitchcablefromthepowerswitchconnectoronthesystemboard.See
“Locatingpartsonthesystemboard”onpage12.
7.Pushthepowerswitchinwardthroughtheholetodisengageitfromthechassis.
Figure87.Removingthepowerswitch
Chapter5.Installingorreplacinghardware81
