7
Commissioning
Using the keypad E82ZBC − Parameter setting
EDK82EV113 DE/EN/FR 8.1
L
118
Status display
Display Meaning Explanation
Ready for operation
Pulse inhibt active Power outputs inhibited
Adjusted current limitation is exceeded in motor−mode or
generator−mode
C0022 (motor mode) or C0023 (generator mode)
Warning active
Fault active
Bargraph display
Value set under C0004 in %
(Lenze setting: Controller load C0056)
Display range: − 180 % ... + 180 % (every bar = 20 %)
Function bar 1
Function Meaning Explanation
Setpoint selection via
Not possible when password protection is active (display
=
"loc")
Display function:
l User menu, memory location 1 (C0517/1), display
l Display active parameter set
Active after every main connection
Code selection
Display of active code in 4−digit display
Subcode selection
Display of active subcode number in 3−digit display
Change of parameter value of a (sub)code
Display of current value in 5−digit display
Display of values longer than 5 digits
H: higher value locations
Display "HI"
L: lower value locations
Display "lo"
Function bar 2
Function Meaning Explanation
Select parameter set 1 ... parameter set 4 for changing
l Display, e.g. PS 2 ( )
l The parameter sets can only be activated via digital
signals (configuration with C0410)
Selection of system bus (CAN) devices The selected device can be parameterised by the current
drive
= function active
Select menu
The user menu is active after mains switching
user
List of codes in the user menu (C0517)
all
List of all codes
funci
Only specific codes for bus function modules,
e.g. INTERBUS, PROFIBUS−DP and LECOM-B
