7
Commissioning
Before switching on
EDK82EV113 DE/EN/FR 8.1
L
114
) Note!
l Do not change the switch−on sequence.
l In the event of an error during commissioning, please see the chapter "Fault
detection and elimination".
To avoid injury to persons or damage to property, check...
... before the mains voltage is connected:
l The wiring for completeness, short circuit and earth fault
l "Emergency−off" function of the whole system
l Motor connection (star/delta) must be adapted to output voltage of controller.
l If you do not use a function module, ensure that the FIF cover is mounted properly
(as delivered).
l If the internal voltage supply X3/20 of e.g. the standard I/O is used, the terminals
X3/7 and X3/39 must be jumpered.
... the most important drive parameter settings before the controller is enabled:
l Are the drive parameters relevant for your application set correctly?
– E.g. configuration of analog and digital inputs and outputs
