Lenze 9300 Series - Page 156

Adjusting the motor
Automatic collection of motor data
6.6
6.6.6

6.6−16
EDSVF9383V EN 7.1−04/2012
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0084

Mot Rs à 0.00 {0.01 mW} 100000.
00
Motor stator resistance
à Value is determined by motor
parameter identification
(C0148, C0149)

6.6−1

6.6−15
C0087

Mot speed à 50 {1 rpm} 36000 Rated motor speed
à depending on C0086
l Motor selection in C0086 set
the corresponding rated motor
speed in C0087
l Change of C0087 sets
C0086 = 0

6.6−1
C0088

Mot current à 0.5 {0.1 A} 1000.0 Rated motor current
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
current in C0088
l Change of C0088 sets C0086 =
0

6.6−1
C0089

Mot frequency à 10 {1 Hz} 5000 Rated motor frequency
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
frequency in C0089
l Change of C0089 sets
C0086 = 0

6.6−1
C0090

Mot voltage à 0 {1 V} 1000 Rated motor voltage
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
l Change of C0090 sets C0086 =
0

6.6−1
C0091

Mot cos phi à 0.50 {0.01 } 1.00 Motor cos j
à depending on C0086
l Motor selection in C0086 sets
the corresponding motor cos j
in C0091
l Change of C0091 sets
C0086 = 0

6.6−1
C0092

Mot Ls à 0.00 {0.01 mH} 6553.50 Motor stator inductance
à Value is determined by motor
parameter identification from
C0088, C0089, C0090 and
C0091
à Motor selection in C0086 sets
corresponding stator
inductance value in C0092

6.6−1
