Lenze 9400

9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Parameterisable function blocks
62 L EDS94TA10040xxxx EN 1.1 - 10/2008
4.14.13 HystTPDiffShaft
4.14.14 HystTPDiffTool
Is an instance of Function
L_SdSetPosition Mark synchronisation (master value):
Conversion of the TP hysteresis selected in the real units of the machine via C03656
into a position in [increments].
Mark synchronisation (master value)
(C 34)
Parameter Possible settings Information
C03656 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.0000 unit
C03657 String of digits Position unit
•Read only
C03658 -2147483647 2147483647 Status
•Read only
Is an instance of Function
L_SdSetPosition Mark synchronisation (setpoint):
Conversion of the TP hysteresis selected in the real units of the machine via C03876
into a position in [increments].
Mark synchronisation (setpoint)
(C 39)
Parameter Possible settings Information
C03876 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.0000 unit
C03877 String of digits Position unit
•Read only
C03879 -2147483647 2147483647 Status
•Read only
