9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Parameterisable function blocks
4.14.27 TrimmingOffsetAdjustment
4.14.28 Virtual_Master
C03704 Set position reached
• Display of output signal
bInTarget.
0 Set position not yet reached.
1Set position reached.
Parameter Possible settings Information
Is an instance of Function
L_SdSetPosition Conversion of the offset position selected in the real units of the machine via
C03676 into a position in [increments].
Master value trimming
(C 37)
Parameter Possible settings Information
C03676 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.5000 unit
C03677 String of digits Position unit
•Read only
C03678 -2147483647 2147483647 Status
•Read only
Is an instance of Function
L_LdVirtualMasterP "Virtual master"
Master value source: Virtual master
(C 30)
Parameter Possible settings Information
C03565 Virtual master operating mode
0 Continuous operation Lenze setting
1 Inching
2 Handwheel function
C03566 0.0000 unit 214000.0000 Target position
• The target position must be
within the cycle.
• Initialisation: 0.0000 unit
C03567 0.0000 unit 214000.0000 Starting position
• The starting position must be
within the cycle.
• Initialisation: 0.0000 unit
C03568/1 -214000.0000 unit/t 214000.0000 Master speed 1
• Initialisation: 1.0000 unit/t
C03568/2 -214000.0000 unit/t 214000.0000 Master speed 2
• Initialisation: 1.0000 unit/t
C03569/1 0.0000 unit/t 214000.0000 Manual speed CW rotation
• Initialisation: 1.0000 unit/t
C03569/2 0.0000 unit/t 214000.0000 Manual speed CCW rotation
• Initialisation: 1.0000 unit/t
