Safety engineering
Appendix
Module internal codes
1
119
EDS94AYAE EN 6.0
Index:Data type:Name:Parameter:
C15060 Output image
BITFIELD_16 9515
d
= 252B
h
Output image of the safety module feedback, shown in channels.
Value is bit coded:
Information
Bit 0 SD-Out1 channel A
Safe output 1
Bit 1 SD-Out1 channel B
Bit 2 reserved
...
Bit 15 reserved
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15100 S bus: Configuration
UNSIGNED_8 9475
d
= 2503
h
Configuration of the safety bus
Selection list
(Lenze setting bold) Information
0 No safety bus
1 PROFIsafe / PROFIBUS
2 PROFIsafe / PROFINET (As of SM301 V1.1)
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15101 Display − DIP switch position
UNSIGNED_16 9474
d
= 2502
h
Display of the DIP switch position
Display area
(min. value | unit | max. value) Information
0 1023
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15111 Safety address
UNSIGNED_16 9464
d
= 24F8
h
Safety address parameterised in the safety module
Setting range
(min. value | unit | max. value) Information
0 65534 Lenze: 0
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15112 Effective safety address
UNSIGNED_16 9463
d
= 24F7
h
Address used in safety module
Display area
(min. value | unit | max. value) Information
1 65534
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
