Specification
Sensor type
passive active
Discrepancy time parameterisable 0 ... 30000 ms (increment: 2 ms)
Input delay parameterisable 0 ... 100 ms (increment: 2 ms)
Input filter time for test pulses fixed 2 ms
Repetition rate of the test pulses is determined by the clock outputs
CLA and CLB
> 50 ms
Error response Sensor input is assessed as OFF state.
Acknowledgement via safety bus or AIE input
Tab. 1−2 Specification of sensor connections
Explanations
ƒ Discrepancy time
Maximum time in which both channels of a safe input may have non−equivalent states
without the safety engineering causing an error response.
ƒ Input delay
Time between the recognition of the signal change and the effective evaluation of an
input signal. As a result, multiple and short signal changes due to contact bounce of the
components are not taken into account.
ƒ Input filter time
Time in which the interference pulses and test pulses are not detected by e.g. active
sensors that are switched on.
The input delay time and the time of the input filters influence the response time. More
information can be found in the "Response times" chapter ( 106).
Codes
Parameter: Name: Data type: Index:
C15033 SD-In discrepancy time
UNSIGNED_16 9542
d
= 2546
h
Maximum time in which both channels of a safe input may have non−equivalent states without the safety
engineering causing an error response.
Setting range
(min. value | unit | max. value) Information
0 MS 30000 Lenze: 10, increment: 2 ms
Subcodes Information
C15033/1 SD-In1 discrepancy time
C15033/2 SD-In2 discrepancy time
C15033/3 SD-In3 discrepancy time
C15033/4 SD-In4 discrepancy time
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
