Lenze E84DGFCG Series User Manual

Installation
Mechanical installation
21
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 2.0 - 10/2013
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.1 Mechanical installation
[5-1] Mechanical installation of the 8400 motec components
 Mounting instructions for Inverter Drive 8400 motec
Here you will find detailed information on the installation.
0.37 ... 3.0 kW 4.0 ... 7.5 kW
E84DG023a
E84DG023b
Legend for fig. [5-1]
1Drive Unit
2 Communication unit
3 Wiring Unit
A Cover of the Drive Unit
EDK84DG... Mounting instructions of the Drive Unit, Communication Unit, Wiring Unit
