6.5 Initial switch-on
Establishing communication
• To establish a communication, the Inverter Drive has to be supplied with mains voltage.
• For EtherNet/IP communication, the Communication Unit has to be supplied with voltage.
If this is not the case, the error message "CE04: MCI communication error" (error no.
01.0127.00002) is output. The error has to be reset in the Inverter Drive in order that the
EtherNet/IP communication can be established.
• The external voltage supply serves to maintain EtherNet/IP communication if the main supply
fails.
External voltage supply
( 24)
• During mains connection, all parameters (codes) are read.
• For addressing the drive, a valid IP configuration is required if communication between the PC/
»Engineer« and the drive is to be effected via EtherNet/IP.
Setting the IP configuration of the Inverter Drive 8400 motec
( 30)
