8 I/O data transfer (implicit messages)
To exchange I/O data (implicit messages) between the host system (scanner) and the drive
(adapter), you have to ...
• Assign the I/O data to the internal ports (MCI) in the drive (adapter):
I/O data mapping
( 47)
I/O configuration in the »Engineer«
( 52)
• Configure the I/O data transfer in the host (scanner):
I/O configuration with »RSLogix 5000« version 19 or lower
( 57)
I/O configuration with »RSLogix 5000« version 20 or higher
( 62)
