1.2 Conventions used
This documentation uses the following conventions to distinguish between different types of
information:
Type of information Writing Examples/notes
Spelling of numbers
Decimal Standard notation Example: 1234
Decimal separator Point The decimal point is always used.
For example: 1234.56
Hexadecimal 0x[0 ... 9, A ... F] Example: 0x60F4
Binary
• Nibble
0b[0, 1] Example: ’0b0110’
Example: ’0b0110.0100’
Text
Program name » « PC software
Example: Lenze »Engineer«
Control element bold The OK button... / the Copy command... / the
Characteristics tab... / the Name input field...
Hyperlink Underlined
Optically highlighted reference to another topic. It is
activated with a mouse-click in this documentation.
Icons
Page reference ( 8) Optically highlighted reference to another page. It is
activated with a mouse-click in this documentation.
Step-by-step instructions

Step-by-step instructions are indicated by a
pictograph.
