Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 2.0 - 10/2013 94
Parameter reference
Parameters of the Communication Unit
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13012
C13016
Parameter | Name:
C13012 | Active Gateway Address
Data type: UNSIGNED_8
Index: 11563 = 0x2D2B
Display of the active gateway address
(Instance attribute 5 (Gateway Address) in the TCP/IP Interface Object (245 / 0xF5)
( 126))
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13012/1 Active gateway address (most significant byte)
C13012/2 Active gateway address
C13012/3 Active gateway address
C13012/4 Active gateway address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13016 | Active Multicast IP Address
Data type: UNSIGNED_8
Index: 11559 = 0x2D27
Display of the active multicast IP address
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13016/1 Multicast IP address (most significant byte)
C13016/2 Multicast IP address
C13016/3 Multicast IP address
C13016/4 Multicast IP address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
