Appendix
Code table
12

330
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C4017 MmaxNegVal 100.0
Limit value for torque limitation
only for movements in the
negative direction of rotation
(neg. speed setpoint).
l 100 % = maximum torque
from C0057
l The torque limitations
(C4018, C4016, C4017) take
effect independently of one
another.
l The torque limitations do not
take effect during "Homing".
0.01 {0.01 %} 100.00
C4018 MmaxVal 100.0
Limit value for torque limitation,
effective for both directions of
rotation (pos. or neg. speed
setpoint).
l 100 % = maximum torque
from C0057
l The torque limitations
(C4018, C4016, C4017) take
effect independently of one
another.
l The torque limitations do not
take effect during "Homing".
0.01 {0.01 %} 100.00
C4020 Brake logic 1
Activate brake logic
 105
0 Brake Off
1 Brake On
2 Brake control via application control
word bit 2
Brake control via control bit 2 in
the application control word:
l 0: brake closed (relay output
is not triggered)
l 1: brake open (relay output is
triggered )
