Lenze i550 Series - Page 161

Inverter i550-C45/400-3 i550-C55/400-3 i550-C75/400-3 i550-C90/400-3
Rated power kW P
N
45 55 75 90
Rated power hp P
N
60 75 100 125
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0-400/480 V
Rated mains current
without mains choke A I
r, AC
- - - -
with mains choke A I
r, AC
66.7 83 113 146
Apparent output power kVA A
ON
60 75 100 121
Rated output current
2 kHz A I
OUT
77 96 124 156
4 kHz A I
OUT
77 96 124 156
8 kHz A I
OUT
77 96 124 140
16 kHz A I
OUT
51.3 63.9 83.1 93.6
Power loss
2 kHz W 920 1137 1539 1841
4 kHz W 980 1210 1640 1961
8 kHz W 1280 1580 2140 2312
16 kHz W 1278 1579 2143 2312
at inverter disablecontroller
inhibit
W 25 30 30 30
Overcurrent cycle 180 s
Max. output current A I
max, out
116 144 186 234
Overload me s t
ol
60 60 60 60
Recovery me s t
re
120 120 120 120
Max. output current during the
recovery me
A 58 72 93 117
Overcurrent cycle 15 s
Max. output current A I
max, out
154 192 248 312
Overload me s t
ol
3 3 3 3
Recovery me s t
re
12 12 12 12
Max. output current during the
recovery me
A 58 72 93 117
Cyclic mains switching 3 mes per minute 1 me per minute
Brake chopper
Max. output current A I
max, 1
98 166 166 333
Min. brake resistance Ω R
min
7.5 4.7 4.7 2.4
Max. motor cable length shielded
without EMC category m 100 100 100 100
Category C1 (2 kHz, 4 kHz, 8
kHz)
m - - - -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 20 20 20 20
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 100 100 100
Weight kg 17.2 24 24 35.6
Weight lb 38 53 53 78.5
Technical data
3-phase mains connecon 480 V
Rated data
161
