9400 HighLine | Commissioning guide
Basic commissioning
Commissioning steps: »Engineer« parameterising dialog: Related documentation:
1. Start »Engineer«. -  Software manual/online help L-force »Engineer«
2. Select the procedure in the Start-up wizard.
• For instance the option "Select component from
catalogue".
Start-up wizard
3. Add the corresponding components from the catalogue
to the project:
• 9400 HighLine controller
• Device modules
• Application
• Motor
4. Select controller from the Project view and make basic
settings: Application parameters tab:  Software manual* 9400 HighLine:
• Set mains voltage & machine parameters. Overview  Drive interface  Machine parameter Chapter "Drive interface  Machine parameter"
• Select motor control type. Overview  Motor Chapter "Motor interface"
• Assign encoder/feedback system. Overview  Motor  Encoder Chapter "Encoder evaluation"
• Set basic functions used. Overview  All basic functions Chapter "Basic drive functions"
5. Optional parameter setting:
• Assign terminal signals. Terminal assignment tab  Software manual* 9400 HighLine:
Chapter "I/O terminals"
• Set application-dependent parameters. Application parameters tab  Software manual* for technology application
• Adapt port assignment and establish network/
communication.
Ports tab  Software manual* for communication module
 Communication manual
• Connect safe sensors/actuators and parameterise
safety functions.
Safe configuration tab for safety module  Manual for safety module
 Software manual* for safety module
6. Connect controller to mains -  9400 Hardware manual
7. Go online, update application, and transmit it to
controller.
 Software manual* 9400 HighLine:
Chapter "Introduction  Communicating with the
controller"
8. Enable controller and control application via terminals/
MotionBus.
Diagnostics tab  Software manual* 9400 HighLine
 Software manual* for technology application
9. Optimise application. Application parameters tab
Oscilloscope tab
* Also part of the Engineer online help
