9400 HighLine | Commissioning guide
Terminal assignment of the technology applications
Positioning sequence control/table positioning
5.3 Positioning sequence control/table positioning
5.4 Electronic gearbox/synchronism
Terminal Signal (Lenze setting)
X3 AI1-/+ Selection for speed override
AI2-/+ Selection for acceleration override
X5 DI1 Quick stop
DI2 Connection of reference switch/touch probe sensor
DI3
DI4
Connection of travel range limit switch for basic function "Limiter".
• DI3 = travel range limit switch positive, DI4 = travel range limit switch negative.
• The inputs respond to the FALSE status (fail-safe).
DI5 Reset error and positioning program
DI6* Start positioning program/Back to starting position
DI7* Stop positioning program (pause)
DI8* Lower table
* Digital input is not assigned in "table positioning" technology application"
Terminal Assignment (Lenze setting)
X5 RFR Controller enable
DI1 Quick stop
DI2 Connection of reference switch or
connection of touch probe sensor for tool synchronism (only for synchronism)
DI3* Connection of touch probe sensor for master value synchronism
DI4 Close coupling
DI5 Reset error
DI6 -
DI7 -
DI8 -
* Digital input is not assigned in "Electronic gearbox" technology application"
