9400 HighLine | Commissioning guide
About this documentation
Conventions used
24 L EDB94AXX6954 DE/EN/FR/ES/IT 4.0
1 About this documentation
This documentation is a guide for (initial) commissioning 9400 HighLine controllers. It
complements the mounting instructions supplied with the controller, the hardware
manual, and the software manual for the controller.
Target group
This documentation is intended for qualified staff according to IEC 364.
Information on validity
The information in this documentation is valid for the following standard devices:
Document history
1.1 Conventions used
This documentation uses the following conventions to distinguish between different types
of information:
Product range Type designation From software version
9400 Servo Drives E94AxHExxxx 4.0
Material number Version Description
13237623 1.0 02/2008 TD05 First edition for 9400 HighLine V03
13265003 2.0 09/2008 TD05 Updated edition for 9400 HighLine V04 and
9400 StateLine V04
13279365 3.0 11/2008 TD05 New edition due to reorganisation of the company
13328367 4.0 02/2010 TD03 Updated edition for 9400 HighLine
Type of information Writing Examples/notes
Spelling of numbers
Decimal separator Point Generally, the decimal point is used.
For example: 1234.56
Text
Program name » « The Lenze PC software »Engineer«...
Window Italics The Message window... / The Options dialog box...
Control element Bold The OK... button / The Copy... command / The
Properties...tab
