9400 HighLine | Commissioning guide
Extended commissioning
Basic drive functions
Positioning
The basic function "Positioning" provides the functionality for executing (travel) profiles.

Parameterising dialog ("Application parameter" tab):
 Overview
 All basic functions
 Positioning
Parameter list ("All parameters" tab):
 Basic drive functions
 LS_Positioner

Software manual 9400 HighLine:
 Basic drive functions
 Positioning
Brake control
This basic function is used for wear free control and monitoring of a holding brake which is connected to the
optionally available brake module. As an alternative, the holding brake can also be controlled and monitored via the
digital inputs/outputs.

Danger!
Bear in mind that the holding brake is an important element of the safety concept of the entire machine.
Therefore be especially careful when commissioning this system part!
Particularly with incorrectly parameterised opening/closing times, loads may sag before the controller
takes over the load.

Stop!
Holding brakes at Lenze motors are not designed for braking during operation. The increased wear
resulting from braking during operation may lead to an early destruction of the motor holding brake!

Parameterising dialog ("Application parameter" tab):
 Overview
 All basic functions
 Brake control
Parameter list ("All parameters" tab):
 Basic drive functions
 LS_Brake

Software manual 9400 HighLine:
 Basic drive functions
 Brake control
