Lenze L-force PROFINET E94AYCER - Page 27

EDK94AYCER DE/EN/FR/ES/IT 6.1
27

klappseite E94ZAYCER−DUMMY_NUM_Reset
X240 Connection for external voltage supply
l 2−pin plug connector with spring connection
44
X241
PROFINET connections
l RJ45 socket according to IEC 60603−7
41
X242
MS
LED status indicators for diagnostics
46
ME
BS
BE
DE
