4 Technical data
General data
Field Values
Order designation E94AYCER
Communication medium CAT 5e
Network topology Tree, star and line
Number of stations Max. 255 in the subnetwork
Max. cable length 100 m
PROFINET stations IO device with real time communication features (RT)
PNO identification no. 0x0106
hex
Device identification
(device ID)
0x9400
hex
Baud rate 100 Mbps
Switching method "Store−and−forward"
Switch latency
Approx. 125 s for maximum telegram length
Voltage supply External supply via separate power supply unit
l "+": U = 24 V DC (20.4 V...28.8 V), I = 130 mA
l "−": reference potential for external voltage supply
Conformities, approvals
l CE
l EAC
l UL
"Servo Drives 9400" hardware manual
Here you can find the ambient conditions and the electromagnetic
compatibility (EMC) specifications applying to the communication module.
