4.2 Mechanical Installation of the Pump/Motor
• The motor can be fixed with four screws on the motor feet (see Figure 4)
• As an alternative the motor can be mounted with four screws on the backside (see Figure 4)
• The motor can be mounted in either the horizontal or vertical position
4.3 Mechanical Installation of the Controller
Hazardous voltage may be present.
In order to avoiding fluid spills shorting mains or other voltages within
the controller, place the controller in a spill protected electrical cabinet.
If explosive flammable gases are present, place the controller in an
explosion-proof cabinet.
Make sure the controller is mounted in a position that allows free air
circulation around the controller. A minimum distance of 10cm (4”) to
other objects above or below the controller casing is recommended.
• Use the Din-Rail bracket to mount the controller.
• If no forced air-cooling is used, mount the controller in upright position.
• The Din-Rail brackets can also be mounted on the controller side according to Figure 5
Use only 3,5 x 6,5mm self-tapping screw for the fixation of the
Din-Rail brackets. The controller may be damaged if other type or
too long screws are used!
