Levitronix BPS-300 User Manual

User Manual for BPS-300
www.levitronix.com
PL-4006-00, Rev07, DCO# 20-144
5
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1
Pump Heads
LPP-300.1
100-90246
Impeller
Pump Casing
Sealing Ring
PFA
PTFE
Kalrez

perfluoroelastomer
1
Fittings
Flaretek 1”
Max. Diff.-Pressure
Max. Flow
2.5 bar / 36.2 psi
58 liters/min / 15.3 gallons/min
Max. Static Pressure
(mounted on motor)
7.7 bar / 112 psi @ 25
0
C / 77
0
F liquid temp.
3.8 bar / 55 psi @ 90
0
C / 194
0
F liquid temp.
Max. Viscosity
50 cP
Max. Liquid Temp.
70
0
C / 194
0
F
(for higher liquid temperatures consult with Levitronix)
2
Motor
LPM-600.2
100-10025
Mechanical Power
300 W
Housing
ETFE coated Aluminum,
waterproofed (IP67 without connectors)
Cable
2 cables, 3m, FEP jacket
Connector
2x circular (AMP types)
3
(7a
+7b)
Standalone
Controller
(User Panel)
LPC-300.1
100-30007
Elec. Voltage / Power
48 V DC / 300 W
Housing Protection
IP20
Interfaces for
Controller
Panel to set speed (automatic storage on internal EEPROM)
PLC with
1x analoge input (“Speed”) 4 - 20 mA
1x digital input (“Enable”) 0 - 24 V (optocoupler)
1x digital output (“Status”) 0 - 24 V (relais)
Accessories
1m power supply cable (Pos 7a) and “Disable” connector (Pos.
7b) are incl. with controller in article package 100-90317
Table 1: Specification of components
1: Kalrez

is a registered trademark of DuPont Dow Elastomers
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
4a
Extension Adaptor
Cable for Sensors
MCAS-600.1-05 (0.5m)
MCAS-600.1-30 (3m)
MCAS-600.1-50 (5m)
MCAS-600.1-70 (7m)
MCAS-600.1-100 (10m)
190-10122
190-10123
190-10124
190-10101
190-10125
Jacket Material
Connectors
PVC
Circular AMP to D-SUB
4b
Extension Adaptor
Cable for Power
MCAP-600.1-05 (0.5m)
MCAP-600.1-30 (3m)
MCAP-600.1-50 (5m)
MCAP-600.1-70 (7m)
MCAP-600.1-100 (10m)
190-10118
190-10119
190-10120
190-10102
190-10121
Jacket Material
Connectors
PVC
Circular AMP to COMBICON
5
(a,b
c,d)
Impeller
Exchange Kit
IEK-600.1
100-90515
Impeller LPI-600.2 (5a)
PFA
O-Ring (5b)
O-Ring, Kalrez

, 72.62 x 3.53
Pump Casing Screws (5c)
Pump Motor Screws
PVDF, 8pcs M6x25
PVDF, 4pcs M6x25
Exchange Tool IET-3.1 (5d)
POM-C
Table 2: Specification of accessories
System Name
Article #
Pump Head
Motor
Controller
Note
BPS-300.1
100-90175
LPP-300.1
LPM-600.2
LPC-300.1
Adaptor/Extension (0.5 - 10m) cables according to Table 2
are included in the system package but have to be ordered as
separate article with specified length.
Table 3: System configuration
