2.7 Basic Dimensions of Main Components
Figure 9: Basic dimensions (in mm and [inch]) of motor LPM-600.x with pump head LPP-600.7/18
Note 1: Non-tolerated dimensions are for reference only. Note2: For other configurations refer to relevant drawings
Inlet

ID = Ø22.2 mm
(BS-4825-3)
8pcs M6x25 Screws (INOX A4)
4pcs M6x25 Screws (INOX A4)
(For Pump head Motor Mounting)
Drain Port

ID = 9.5mm
(BS-4825-3)
(LPP-600.18 pump head
is without drain port)
Outlet

ID = Ø22.2 mm
(BS-4825-3)
