Levitronix PuraLev 600MU User Manual

User Manual for PuraLev
®
600MU
www.levitronix.com
PL-4033-00, Rev09, DCO# 20-144
5
System Name
Article #
Pump Head
Motor
Controller
Note
PuraLev
®
600MU.1
PuraLev
®
600MU.2
PuraLev
®
600MU.4
PuraLev
®
600MU.5
100-90590
100-90591
100-90593
100-90594
LPP-600.7 (PVDF)
(with drain port)
LPM-600.5
LPM-600.5
LPM-600.4
LPM-600.4
LPC-600.1-02
LPC-600.2-02
LPC-600.1-02
LPC-600.2-02
Adaptor/Extension cables according to Table 3 have to be
ordered as separate article.
ATEX Cable Sealing System can be ordered according to
Table 4.
Certifications: CE, IECEE CB scheme, ETL (NRTL), ATEX
and IECEx.
PuraLev
®
600MU.7
PuraLev
®
600MU.8
PuraLev
®
600MU.10
PuraLev
®
600MU.11
100-90596
100-90597
100-90599
100-90632
LPP-600.18
(PVDF)
(without drain port)
LPM-600.5
LPM-600.5
LPM-600.4
LPM-600.4
LPC-600.1-02
LPC-600.2-02
LPC-600.1-02
LPC-600.2-02
PuraLev
®
600MU.14
PuraLev
®
600MU.15
PuraLev
®
600MU.17
PuraLev
®
600MU.18
100-91325
100-91326
100-91328
100-91329
LPP-600.27 (SS)
(without drain port)
LPM-600.13
LPM-600.13
LPM-600.12
LPM-600.12
LPC-600.1-06
LPC-600.2-06
LPC-600.1-06
LPC-600.2-06
Table 1: Standard system configurations with motor controller and pump head
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
1b
Multi-Use Pump Heads
(PVDF)
LPP-600.7
(with drain port)
LPP-600.18
(without drain port)
100-90287
100-90548
Impeller / Pump Housing
Housing Sealing
In-/Outlet Fittings
Max. Flow / Max. Diff.-Pressure
Max. Viscosity / Max. Liquid Temp.
Wet Pump Volume/Surface
Sterilization Methods
PFA / PVDF (FDA, USP Class VI, BSE/TSE/Animal free)
Triclamp EPDM (FDA, USP Class VI, BSE/TSE/Animal free)
drain port (Standard: BS-4825-3)
75 liters/min (20 gallons/min) / 3.2 bar (46 psi)
50 cP / 90
°
C (194
°
F)
113 ml / 363 cm
2
(without drain port)
SIP (Steam in Place), CIP (Clean in Place), Autoclaving
1
1c
Multi-Use Pump Heads
(Stainless Steel)
LPP-600.27
(without drain port)
100-91319
Impeller / Pump Housing
Housing Sealing
In-/Outlet Fittings
Max. Flow / Max. Diff.-Pressure
Max. Viscosity / Max. Liquid Temp.
Wet Pump Volume/Surface
Sterilization Methods
Stainless Steel (EN 1.4435 / AISI 316L)
O-ring (DIN/SO 11864) EPDM (FDA, USP Class VI, BSE/TSE/ADI)
(Standard: ASME)
75 liters/min (20 gallons/min) / 3.0 bar (43.5 psi)
30 cP / 90
°
C (194
°
F)
115 ml / 374 cm
2
SIP (Steam in Place), CIP (Clean in Place)
2a
2b
Motor (ATEX / IECEx)
LPM-600.5
LPM-600.13
2
100-10039
100-10150
Housing
Cable / Connectors
Epoxy (anti-corrosive) coated Aluminum, waterproofed (IP67)
2x 3m cables with PVC jacket / 2x circular (M23, IP-67)
ATEX / IECEx Marking
II 3G Ex nA IIC T5 Gc, II 3D Ex tc IIIC T100°C Dc
2c
2d
Motor (ATEX / IECEx)
LPM-600.4
LPM-600.12
2
100-10038
100-10149
Housing
ETFE (chemical resistant) coated Aluminum, waterproofed (IP67)
Cable / Connectors
2x 3m cables with FEP jacket / 2x circular (M23, IP-67)
3a
Standalone
Controller
(User Panel)
LPC-600.1-02
LPC-600.1-06
2
100-30033
100-30086
(Power cable and
PLC connector incl.)
Voltage / Power
48V DC / 600 W
Interfaces
Panel to set speed (automatic storage on internal EEPROM)
PLC with
 4 - 20 mA
1x digital input  0 - 24 V (optocoupler)
 0 - 24 V (relais)
Standard Firmware
For LPC-600.1-02: D6.25 For LPC-600.1-06: D7.25
3b
Extended
Controller
(PLC and USB)
LPC-600.2-02
LPC-600.2-06
2
100-30034
100-30087
(Power cable and
PLC connector incl.)
Interfaces
PLC with
- up to 4 digital inputs 0 - 24V (optocoupler)
- up to 4 digital outputs 0 - 24 V (relais)
- up to 2 analog inputs 4 - 20mA
- up to 2 analog inputs 0  10 V
- up to 2 analog outputs 0  5 V
USB interface (for service and system monitoring)
Standard Firmware
For LPC-600.2-02: D6.48 For LPC-600.2-06: D7.48
Table 2: Specification of standard components
Note 1: See Section 6.7.
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
4a
Extension Adaptor
Cable for Sensors
MCAS-600.2-05 (0.5m)
MCAS-600.2-30 (3m)
MCAS-600.2-50 (5m)
MCAS-600.2-70 (7m)
MCAS-600.2-100 (10m)
190-10226
190-10238
190-10127
190-10105
190-10239
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to D-SUB
4b
Extension Adaptor
Cable for Power
MCAP-600.2-05 (0.5m)
MCAP-600.2-30 (3m)
MCAP-600.2-50 (5m)
MCAP-600.2-70 (7m)
MCAP-600.2-100 (10m)
190-10227
190-10240
190-10126
190-10106
190-10241
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to COMBICON
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
5a
Air Cooling Module
ACM-600.2
190-10140
Material / Connection Port
Air Pressure

~1 - 3 bar (14  43 psi)
5b
Air Cooling Module
ACM-600.3 (ATEX)
190-10410
Material / Connection Port
Air Pressure
PP EL-S (black, 
~1 - 3 bar (14  43 psi)
6a
Fan Cooling Module
FCM-600.1
190-10401
Housing / Cable Spec.
Supply Spec. / IP Rating
PP (+ 20% Talkum) white / PP jacket, 3m, circular sealed M12
connector (PP).
24 VDC, 3.4 W / IP-65 (fan is IP68 rated).
6b
Fan Cool. Module Cable
FCC-1.1-50 (5 m)
FCC-1.1-100 (10 m)
190-10407
190-10408
Specification
PP cable jacket with circular M12 connector (PP) to open wires
7
(A-F)
ATEX Cable
Sealing System
ACS-A.1
(Roxtec)
100-90292
Sleeve (A) and Gasket (B)
Frame (C)
2x Cable Module (D)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (E) and measurement
plates (F) are included.
8
AC/DC Power Supply
TSP 600-148-M
(M = Modified Levitronix design
from Traco)
100-40013
(Traco ID Number:
T1068-01A)
Voltage / Power Output
Voltage Input
Certification or Standards
48 VDC / 600 W
85  265 VAC (automatic detection)
CB, UL, CSA, Semi F47
9
Autoclaving Reinforcing
Tool
ART-600.1
190-10281
Purpose
Material / Mount. Screws
For stabilization of housing of PVDF pump heads during autoclaving
Anodized Aluminum / 4 pcs M6 x 25mm (Stainless steel)
Table 4: Specification of accessories
