Page #65 background imageLoading...
Page #65 background image
Setting up the fax function using fax server
Notes:
This feature lets you send fax messages to a fax service provider that supports email receiving.
This feature supports outgoing fax messages only. To support fax receive, make sure that you have a
devicebased fax, such as analog fax, etherFAX, or Fax over IP (FoIP), configured in your printer.
1 Open a web browser, and then type the printer IP address in the address
field.
Notes:
View the printer IP address on the home screen. The IP address appears as four sets of numbers
separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the web page correctly.
2 Click Settings > Fax.
3 From the Fax Mode menu, select Fax Server, and then click Save.
4 Click Fax Server Setup.
5 In the To Format field, type [#]@myfax.com, where [#] is the fax number and myfax.com is the fax
provider domain.
Notes:
If necessary,
configure
the Reply Address, Subject, or Message
fields.
To let the printer receive fax messages, enable the devicebased fax receive setting. Make sure that
you have a devicebased fax configured.
6 Click Save.
7 Click Fax Server Email Settings, and then do either of the following:
Enable Use Email SMTP Server.
Note: If the Email SMTP settings are not configured, then see “Configuring the email SMTP settings
on page 51.
Configure the SMTP settings. For more information, contact your email service provider.
8 Apply the changes.
Setting up fax using a standard telephone line
Note: These instructions apply only to printers that support analog fax. For more information, see “Supported
fax” on page 62.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not set up this product or make
any electrical or cabling connections, such as the power cord, fax feature, or telephone, during a
lightning storm.
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not use the fax feature during a
lightning storm.
Faxing 65
