Lexmark MS317 Service Manual

Menus list
Paper Menu Reports
Network/Ports
3
Default Source
Paper Size/Type
Configure
MP
Substitute Size
Paper Texture
Paper Weight
Paper Loading
Custom Types
Universal Setup
Menu Settings Page
Device Statistics
Network Setup Page
1
Profiles List
Print Fonts
Print Directory
Asset Report
Active NIC
Standard Network
2
Reports
Network card
TCP/IP
IPv6
Wireless
AppleTalk
Standard USB
SMTP Setup
Security Settings
Security Audit Log
Set Date and Time
General Settings
Print Settings
1
Depending on the printer setup, this menu item appears as Network Setup Page or Network [x] Setup Page.
2
Depending on the printer setup, this menu item appears as Standard Network or Network [x].
3
The menu items in this menu appear only in network printers or printers connected to print servers.
Diagnostics menu
The Diagnostics menu group consists of menus, settings, and operations that are used to diagnose printer
problems.
Entering the Diagnostics menu
1 Turn o the printer.
2 Press and hold and OK.
3 Turn on the printer.
4 Release the buttons when a line of dots appears.
Registration
These settings adjust the margins of the black plane.
To set the Registration:
1 Print a Quick test page.
a From the Diagnostics menu, navigate to:
Registration > Quick Test
b Retain this page to determine the changes you need to make to the margin settings. The alignment
diamonds in the margins should touch the margins of the page.
4514-330
Service menus
163

Lexmark MS317 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 50, 000 pages
Standard Connectivity	USB 2.0, Ethernet
Standard Memory	128 MB
Processor	800 MHz
Duplex Printing	Manual
Input Capacity	250 sheets
Output Capacity	Up to 150 sheets
First Page Out Time	6.5 seconds
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Linux, Mac
