Lexmark MS510 Series - Media Present Sensor Removal

To Next Page

To Previous Page

6 Position the printer so that it sits on its left side.

7 Disconnect the cable from the media present sensor (A).

8 From inside the printer, release the three latches (B).

4514-630, -635, -636

Repair information

231
