Lexmark MS622

3 Remove the screw (B).
B
4 Lift the top cover enough to remove the cartridge gearbox.
5 While lifting the cover, disconnect the cable from the gearbox, and then remove the gearbox.
MPF solenoid removal
1 Remove the left cover. See “Left cover removal” on page 177.
2 Remove the screw (A).
A
3 Cut the cable, and then remove the solenoid.
4600-830, -835, -895
Parts removal
185
