Lexmark MS622

4 Disconnect the three cables (E).
E
E
5 Remove the power supply.
Duplex assembly removal
1 Remove the rear cover. See “Rear door and cover removal” on page 234.
2 Remove the power supply. See “Power supply removal” on page 216.
3 Position the printer on its right side.
4600-830, -835, -895
Parts removal
218
