Lexmark MS622

5 Remove the two screws (B).
B
6 Remove the redrive gear plate.
Top side removals
Top cover removal
1 Remove the right cover. See “Right cover removal” on page 186.
2 Remove the left cover. See “Left cover removal” on page 177.
3 Remove the rear cover. See “Rear door and cover removal” on page 234.
4 Open the front door.
4600-830, -835, -895
Parts removal
238
