Lexmark MS622

G
Sensor (MPF paper present) removal
1 Open the front door.
2 Remove the screw (A).
A
3 Open the controller board access cover, disconnect the cable JMPFPP1, and then release the cable.
4 Remove the sensor.
Installation note: Pay attention to the position of the MPF sensor
flag
when installing the sensor.
4600-830, -835, -895
Parts removal
212
