Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1172 1 1 Top cover
“Top cover removal” on page 238
2 41X1231 1 1 Output extender --
3 41X1170 1 1 Rear door and cover
“Rear door and cover removal” on
page 234
4 41X1232 1 1 Rear access door --
540X8521 1 1Dust cover --
6 41X1166 1 1 Right cover
“Right cover removal” on page 186
7 41X1233 1 1 Right access cover --
8 41X1164 1 1 Nameplate
“Nameplate removal” on page 201
9 41X1168 1 1 Left cover
“Left cover removal” on page 177
4600-830, -835, -895
Parts catalog
260
