Assembly 7: Paper transport 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1183 1 1 Jam access cover
Jam access cover removal” on page 206
2 41X1184 1 1 Front input guide
“Front input guide removal” on page 213
3 41X1176 1 1 Duplex assembly
“Duplex assembly removal” on page 218
441X1182 1 1MPF gearbox
“MPF gearbox removal” on page 179
5 41X2255 1 1 Fuser actuator
“Fuser actuator removal” on page 182
6 41X2256 1 1 Redrive gear plate
“Redrive gear plate removal” on page 237
4600-830, -835, -895
Parts catalog
272
