GS350_OM_OM30D41U_(U)
665
6-3. Do-it-yourself maintenance
6
Maintenance and care
9 DOME 7. 5
Personal lights, ornament lights, trunk light,
footwell lights, door courtesy lights, vanity
lights, rear door inside handle illuminations,
power trunk opener and closer
10 EPS 80 EPS
11 ARS 80 Dynamic rear steering
12 HTR 50 Air conditioning system
13 ABS NO.1 40 VDIM
14 LUG J/B ALT 50 Luggage compartment junction block
15 PTC NO.1 50 PTC heater
16 PTC NO.2 50 PTC heater
17 ABS NO.2 50 VDIM
18 ST 30 Starting system
19 H-LP LO 30 Headlights, H-LP RLY
20 D/C CUT 30 DOME, MPX-B
21 DCM 7. 5 DCM
22 ECU-B 7. 5 Smart access system with push-button start
23 ALT-S 7. 5 Charging system
24 ETCS 10
Multiport fuel injection system/sequential
multiport fuel injection system
25 HORN 10 Horn
26 R/B-B 20 EPS-B, ODS, TV
27 P/I-B NO.1 50 Headlights, daytime running lights
28 EPB 30 Parking brake
29 LUG J/B-B 40 Luggage compartment junction block
30 FAN NO.1 80 Electric cooling fans
31 LH J/B ALT 60 Left-hand junction block
32 H-LP CLN 30 Headlight cleaner
Fuse Ampere Circuit
To Next Page
