D. UNDER THE HOOD (Conti nued)
69
2007MY LS460L/LS460
4. Set the screen as shown in
the illustration
Hint:
D Stand the screen perpen-
dicular to the ground.
D Align the V line on the
screen with the center of
the vehicle.
D12bï4
LS10074
Aligning distance is 32.8 ft.:
VRHLine
90_
VLHLine
VLine
90_
32.8 ft .
HLine
D12bï4
LS10075
Aligning distance is 9.84 ft.:
VRHLine
90_
VLHLine
VLine
90_
9.84 f t.
HLine
