FRONT LICENSE PLATE MOUNTING BRACKET & LICENSE PLATE INSTALLATION – PD069-06 September 22, 2006
Page 2 of 2
3. Install the mounting bracket to the front bumper cover at holes “A” using the two
supplied self-tapping screws.
4. Install the front license plate to the
mounting bracket at holes “B” using
two bolts of the size listed below.
Use non-corroding bolts with the
following dimensions to install the
front license plate:
Nominal Length: 15.0 mm (0.59 in.)
Diameter: 6.0 mm (0.24 in.)
Installation
Procedure
(Continued)
Bolts into Holes “B”
License Plate
15.0 mm (0.59 in.)
6.0 mm
(0.24 in.)
To Next Page
