FRONT FLOOR UNDER COVER INSTALLATION DURING PDS – PD070-06 September 22, 2006
Page 2 of 2
2. Install the left side front floor
under cover.
A. Install the under cover (for front
side) and the fender apron with
the 2 clips included.
NOTE:
S Install the under cover clips in the
holes on the left and right side of
the fender apron screw.
S The letter “LH” is on the back of the
left side front floor under cover.
B. Install the under cover (for
rear side) with the 2 clips that
are included.
3. Repeat step 2 to install the right floor
under cover.
Installation
Procedure
(Continued)
Clips
To Next Page
