TIRE PRESSURE WARNING VALVE/SENSOR ACTIVATION – PD072-06 September 22, 2006
Page 2 of 5
S The Low Tire Pressure Warning Light
will blink until all the tire pressure
warning valves/sensors are activated.
S The Diagnostic Trouble Codes (DTCs)
listed below may be stored in the
TPWS ECU until the tire pressure
warning valves/sensors are activated.
S The multi-information display will read
“Check Tire Pressure System”.
S The “Check Tire Pressure System” on
the multi-information display will
disappear when the tire pressure
warning valve/sensors are activated.
S The DTCs will automatically clear
when the tire pressure warning
valves/sensors are activated.
DTC *1 DTC *2 DTC
11 C2111 Transmitter ID1 Inactive (Sleep Mode)
12 C2112 Transmitter ID2 Inactive (Sleep Mode)
13 C2113 Transmitter ID3 Inactive (Sleep Mode)
14 C2114 Transmitter ID4 Inactive (Sleep Mode)
15 C2115 Transmitter ID5 Inactive (Sleep Mode)
DTC *1: Indicated by flashing of the Low Tire Pressure Warning Light.
DTC *2: Indicated on the Lexus Diagnostic Tester.
Reference
Low Tire Pressure
Warning Light
To Next Page
