LG-Ericsson iPECS-MG - User Manual

Questions and Answers

T
Tammy StarkAug 3, 2025
How to fix LG-Ericsson iPECS-MG PBX system power failure?
- A
  Alison CervantesAug 3, 2025
  If the LG-Ericsson PBX system experiences a power failure, first ensure the fuse/breaker is working and AC power is reaching the outlet. Check the PSU fuse and LD21, LD22 on the backplane; replace the PSU if needed. Also verify the MPB is installed and check for short circuits by removing boards one at a time from the KSU. Finally, check the DC output status on the MB if LD4 LED is off on the MPB.
Z
zfergusonAug 7, 2025
What to do if LG-Ericsson iPECS-MG PBX expansion KSU does not operate?
- K
  Kevin MckenzieAug 8, 2025
  If your LG-Ericsson PBX expansion KSU does not operate, use the proper power-up sequence: first, turn on all EKSUs, then power on the Basic KSU. Press the MPB Reset button to reset the system. Also, check the expansion cable for connection and condition. Ensure that the BKSU power is on, the MPB is installed, the PSU is plugged in, AC power is delivered to the outlet, and the fuse/breaker is operational.
O
oleonardAug 13, 2025
How to troubleshoot LG-Ericsson iPECS-MG DKT that does not operate?
- K
  karenortegaAug 13, 2025
  If your LG-Ericsson PBX DKT does not operate, replace the malfunctioning board if it is a bad DTIB circuit. Check the connection between the DSIU/DTIB and DKT terminals, ensure proper wiring, and repair any broken connections. Also, ensure the distance between the board and DKT does not exceed specifications. If the DKT is bad, plug it into a verified working extension port; if it still fails, replace the DKT.
M
Matthew StewartAug 17, 2025
Why is there noise on LG-Ericsson iPECS-MG PBX external MOH and paging port?
- M
  Mary RoseAug 18, 2025
  If you experience noise on the external MOH and paging port of your LG-Ericsson PBX, ensure the wiring is not near equipment generating high RF interference and contains no coils. Use shielded pair wiring and ground the shield. Also, decrease the output level of the external music source if the input level is excessive.
T
Tracey MahoneyAug 23, 2025
What to do if LG-Ericsson iPECS-MG SLT does not operate?
- J
  Justin FowlerAug 23, 2025
  If your LG-Ericsson PBX SLT does not operate, exchange the extension board if there is a bad DSIU/SLIB. Check the connection between the DSIU/SLIB port and SLT.
K
kpearsonAug 27, 2025
How to fix LG-Ericsson PBX CO line operation failure?
- D
  Dennis OwensAug 28, 2025
  If you are experiencing CO line operation failure with your LG-Ericsson PBX, check the CID type assigned for the CO line and ensure CID is provided from the carrier. Check all connections. If it's one CO line or board, replace the board.

Summary

Regulatory Information

FCC Interference Statement

Statement about FCC compliance and interference limits for digital devices.

Revision History

Introduction

Important Safety Instructions

Crucial safety guidelines for operating the equipment to prevent hazards.

Precaution

Precautions to avoid system interference and damage.

Manual Use

Overview of the document's structure and purpose.

System Overview

iPECS-MG System Highlights

Key features and capabilities of the iPECS-MG system.

System Connection Diagram

Visual representation of system components and their interconnections.

System Components

List and description of the system's hardware components and optional boards.

General Specifications

Technical specifications including dimensions, environment, and electrical details.

System Capacity

Details on the system's port capacity and resource limits.

Installation Overview

General Installation Procedure

Step-by-step guide for the overall installation process of the iPECS-MG system.

Types of Connectors

Description and purpose of various connectors used in the system.

Installation and Safety Precautions

Guidelines and precautions to ensure safe and correct installation.

KSU Installation

BKSU Unpacking

Instructions for unpacking the Basic KSU and its accessories.

EKSU Unpacking

Instructions for unpacking the Expansion KSU and its accessories.

KSU Diagram, Exterior and Dimension

Visual layout and physical dimensions of the KSU.

Basic KSU Mounting

Procedures for mounting the KSU in a rack or on a wall.

Expansion KSU Installation

Steps for installing and connecting expansion KSUs.

Power Supply Unit Wiring

Guidance on wiring the power supply unit and ground connection.

Board Installation

General Board Install Procedure

General steps and precautions for installing system boards.

Main Processing Board

Details on the MPB, its functions, and installation.

CO Line Boards

Information on CO Line Interface Boards (LCOB) and their installation.

Extension Boards

Details on various extension interface boards like SLIB and DTIB.

Function Boards

Information on function boards like VMIB, AAIB, and VOIB.

Serial to Audio Cable Specification

Serial to Audio Cable Wiring

Wiring instructions for the serial to audio cable.

Cable Dressing

Wall Mount Wiring

Instructions for dressing cables in a wall mount installation.

Rack Mount Wiring

Instructions for dressing cables in a rack mount installation.

LG-Ericsson iPECS-MG Specifications

General

VoIP Protocols	SIP, H.323
VoIP Support	Yes
TDM Support	Yes
Power Supply Frequency	50/60 Hz
Humidity	10% to 90% non-condensing
Management Interface	Web-based, CLI
Power Supply	AC 100-240V
Mobility	Yes
Unified Communications	Yes
Network Interfaces	Gigabit Ethernet
Operating Temperature	0°C to 40°C
