2.3 System Components
ITEM
OPTION
BOARD
DESCRIPTION
BKSU Basic KSU
EKSU Expansion KSU
PSU Power Supply Unit (350W)
Main Processor Board 100 w/6 DKT, 6 SLT MPB100
MODU Modem Unit
Main Processor Board 300 w/6 DKT, 6 SLT
Main Board
MPB300
MODU Modem Unit
LCOB4 CMU4 4 LCO Interface Board
LCOB8 CMU4 8 LCO Interface Board
LCOB12 CMU4 12 LCO Interface Board
Trunk
Boards
E1/PRIB Digital CO Interface Board (1 PRI or 1 E1R2)
SLIB12 12 port SLT Interface Board
SLIB12C 12 port SLT Interface Board (RJ21)
SLIB24 24 port SLT Interface Board
SLIB24C 24 port SLT Interface Board (RJ21)
DTIB12 12 port DKT Interface Board
DTIB12C 12 port DKT Interface Board (RJ21)
DTIB24 24 port DKT Interface Board
Extension
Boards
DTIB24C 24 port DKT Interface Board (RJ21)
VMIB Voice Mail Interface Board (8 channels, 100 hrs)
AAIB Auto Attendant Interface Board (8 channels)
VOIB8 8 channel VoIP Interface Board
Function
Boards
VOIB24 24 channel VoIP Interface Board
GDC-600B DECT Base Station (6 channels per Base) use w/WTIB
WTIB4 4 channel DECT Wireless Terminal Interface Board
WTIB8 8 channel DECT Wireless Terminal Interface Board
DECT
WMK Wall Mount Bracket
