LG-Ericsson iPECS-MG - Switch and LED Functions

iPECS-MG Hardware Description and Installation Manual Issue 1.1
DECT INSTALLATION August, 2010
36
The default clock is assigned based on the board type, KSU, and slot as below.
- Board – PRIB>BRIB2/BRIB4>Internal Clock
- KSU – 1’st KSU>2’nd KSU>3’rd KSU
- Slot – Slot 1>Slot 2>…>Slot 18
5.3.2.1 Switch and LED Functions
BRIB Line Mode Switch SW1
SWICTH FUNCTION ON OFF
SW1-1 Line #1 mode S-mode T-mode
SW1-2 Line #2 mode S-mode T-mode
SW1-3 Line #3 mode S-mode T-mode
SW1-4 Line #4 mode S-mode T-mode
Note the default setting is T Mode for all switches. SW1-3 and SW1-4 are for BRIB4 only.
BRIB Terminating Resistor (100-Ohm)
SWITCH FUNCTION ON OFF
SW6-1 Line 1 TX resistor Terminate Open
SW6-2 Line 1 RX resistor Terminate Open
SW8-1 Line 2 TX resistor
SW8-2 Line 2 RX resistor
SW10-1 Line 3 TX resistor
SW10- 2 Line 3 RX resistor
SW12-1 Line 4 TX resistor
SW12-2 Line 5 RX resistor
BRIB Power Feed
SWITCH FUNCTION ON OFF
SW7-1 Line 1 Power Feed (-40V) Feed Open
SW7-2 Line 1 Power Feed (Ground) Feed Open
SW9-1 Line 2 Power Feed (-40V) Feed Open
SW9-2 Line 2 Power Feed (Ground) Feed Open
SW11-1 Line 3 Power Feed (-40V) Feed Open
SW11- 2 Line 3 Power Feed (Ground) Feed Open
SW13-1 Line 4 Power Feed (-40V) Feed Open
SW13-2 Line 4 Power Feed (Ground) Feed Open
LED Indication, BRIB2
NO FUNCTION STATUS
LD1
LD3
Line 1 status Red: ON = Error
Blue: ON = In-use, OFF = Idle
LD2
LD4
Line 2 status Red: ON = Error
Blue: ON = In-use, OFF: = Idle
